High-Voltage Cabling for Next-Gen EV Architectures

Designed for seamless harness assembly and engineered to meet rigorous OEM automotive standards, our high-voltage cables power every critical powertrain node from 800V fast-charging systems to high-rpm electric drive units.





High-Current Transmission in Ultra-Compact Battery Spaces

Integrating high-voltage battery packs with Power Distribution Units (BDU) and Inverters requires exceptional thermal management and extreme bendability in tight spaces. Our HV cables utilize flexible Class 5/6 fine-stranded tinned/bare copper conductors combined with cross-linked XLPE/Silicone rubber insulation, enabling tight bending radii (<3*OD) without stress cracking.



Technical Highlights: Rated Voltage:600V/1000V DC (Optional 1500V)

Temp Rating: -40°C to +150°C / +180°C

Standards: ISO 19642 / LV 216 / QC/T 1037 / UL 758







Built for 800V+ High-Voltage DC Fast Charging Architectures

Modern EV platforms demand rapid energy intake without excessive temperature rise at the charging inlet and OBC interfaces. Optimized for high-voltage fast-charging, our cables accommodate continuous high-current loads while maintaining low contact resistance and excellent ampacity retention under elevated ambient temperatures.



Technical Highlights: Rated Voltage: Up to 1500V DC

Ampacity: Up to 400A+ continuous current

Halogen-Free & RoHS/REACH Compliant

Dielectric Withstand: 3000V AC/1min without breakdown.
